Shipping, tax, and handling costs is not included in the price.
|
|
Rare and hard to find Ortofon SPU Meister Silver MK II MC cartridge.
The SPU Meister Silver G MkII has been improved on coil winding material, stylus, and magnet
SPU Meister Silver G MK II
The masterpiece of Mr. Robert Gudmandsen, the SPU Meister Silver was introduced in 1996 as a technological improvement of great importance. Ortofon has succeeded in having the purest silver wire ever produced for the coil winding process.
The SPU Meister Silver G MkII has been improved on coil winding material, stylus, and magnet. The cartridge has been outfitted with high purity multi-conductor 6-nines Silver wire (of a purity of 99.9999 %) for a more open and revealing high-end presentation.
The nude elliptical stylus tip mass has been decreased by a factor of more than 50%, resulting in increased tracking ability and reproduction of microdynamic detail. The generator system has been revised to produce a slightly higher output to ensure compatibility with a wider range of moving coil transformers and active MC preamplifiers.
Specifications
Channel balance: 1dB at 1 kHz
Output voltage: 0.3mV at 1 kHz, 5cm/sec
Channel separation: 20dB at 1 kHz
Frequency response: 20~20,000 Hz 2/-1 dB
Tracking ability: 70um at 315 Hz
Compliance: 8um/mN dynamic, lateral
Stylus: Nude Elliptical
Stylus radius: r/R 8/18 £gm
Stylus pressure range: 3.0~5.0 gram (30-50 mN)
Recommended: 4.0 gram (40 mN)
Tracking angle: 20 degree
Internal impedance: 3 ohm DC resistance
Recommended load impedance: 10 ohm
Coil wire material: 99.9999 Silver
Cartridge body material: Ground wood and resin composite
Cartridge colour: Shiny black
Net weight: 28 gram |
|
|
| Goods sold are not returntable. Subject to terms and conditions exchange of goods can be considered. |
|
